For holding heavier kitchen appliances
In fully extended position the shelf lies flush with the worktop
Lift up to release the locking mechanism when returning to stored position
Load bearing capacity 8 kg
For cabinet widths 350 - 600 mm. Installation width is optional between 300 mm and 568 mm as the two arms are completely separate
Swivel depth 445 mm
Maximum shelf width is internal cabinet width less 90 mm, shelf depth = 300 mm
The cranked mounting brackets prevent the door hinges fouling the shelf when raised
When mounted directly beneath the worktop the smallest remaining usable height within the cabinet is 340 mm
Galvanized steel 150N tension springs
White lacquered steel
